Monolithic SHG/THG Fan-out PP-Mg:SLT

A new robust configuration combined two QPM features: Monolithic and Fan-out structure

Advantages of Monolithic Fan-out PP-Mg:SLT

  • More than 100mW of third harmonic is obtained from one dvice with one temperature control
  • Compact convertor
  • Less problem of group velocity miss-match between 3 wavelengths (fundamental, second harmonic and third harmonic)



Example setup

monolithic eng 2
