Pulsed UV/Green Fiber Laser
Features
- Compact (portable)
- High peak power
- High repetition rate
- Compatible design
Application
- Underwater inspection
- Raman spectroscopy
- Aerosol detection
- Sensing (LIDAR)
Specification(preliminary@25℃）
| Model | UV | Green |
| Mode of operation | Pulsed | Pulsed |
| Wavelength | 355nm | 532nm |
| Pulse energy | ～1.6μJ | ～12μJ |
| Peak power | ～1.6kW | ～12kW |
| Average power | ～80ｍW | ～500ｍW |
| Power tunability | 20-100% | |
| Output Type | Free space | |
| pulse repetition rate | 50kHz | |
| Pulse duration | ～1ns | ～1ns |
| Polarization | Linear(vertical) | |
| Beam Quality(M2) | <1.5 | <1.4 |
| Fiber laser size | 120(W)×27(H)×120(L)mm3 | |
| Convertor size | 36(W)×36(H)×97(L)mm3 | 36(W)×36(H)×40(L)mm3 |
Option
- Collimated output
- Other Wavelength
- Customized packages, OEM
- Dual wavelength output (1064 nm/532 nm)
Above products are based on results obtained from a project commissioned by the New Energy and Industrial Technology Development Organization (NEDO).
